WebSockets (WS)

WebSockets provide full-duplex communication between client and server over a single, long-lived connection. Unlike Server-Sent Events (SSE), which are strictly one-way, WebSockets allow both client and server to send messages at any time, making them ideal for chat systems, collaborative tools, and low-latency control loops.

— MDN Web Docs

Description

RFC: The WebSocket Protocol: https://datatracker.ietf.org/doc/html/rfc6455

The WebSocket protocol (ws:// or wss:// for TLS) upgrades a standard HTTP connection into a persistent, bidirectional channel. Once established, either side can send arbitrary binary or text messages at any time—without the overhead of HTTP headers or reconnection logic.

Compared to HTTP-based polling or SSE, WebSockets offer:

• Low latency: no need to establish a new connection for every message
• Bidirectional flow: both client and server can initiate messages

Rama supports WebSocket connections natively, allowing you to both expose WebSocket endpoints and interact with them as a client—all with async-first ergonomics.

This is the happy flow for a http/1.1 upgrade. Note that rama also supports websockets over h2. The flow for this is the same, but the details differ. Most relevant for this flowchart it changes the request method to CONNECT and the response status to 200 OK.

HTTP/1.1 Request Example

• Request:

GET / HTTP/1.1
Host: example.com
Connection: upgrade
Upgrade: websocket
Sec-WebSocket-Version: 13
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==

• Response:

HTTP/1.1 101 Switching Protocols
Connection: upgrade
Upgrade: websocket
Sec-WebSocket-Accept: s3pPLMBiTxaQ9kYGzzhZRbK+xOo=

The interaction begins with a client making a standard HTTP GET request to a WebSocket endpoint, but including an Upgrade: websocket header. If accepted, the server replies with a 101 Switching Protocols response. From this point forward, both sides can send frames over a persistent TCP connection.

Messages can be either text or binary.

h2 WebSocket support

RFC: Bootstrapping WebSockets with HTTP/2: https://datatracker.ietf.org/doc/rfc8441/

While traditional WebSockets rely on HTTP/1.1's Upgrade and Connection: upgrade headers to switch protocols, HTTP/2 doesn’t support these connection-wide semantics due to its stream-multiplexing architecture. Instead, RFC 8441 introduces a new mechanism: an extended CONNECT method combined with a new pseudo-header :protocol: websocket. When the SETTINGS_ENABLE_CONNECT_PROTOCOL flag is set, clients may initiate a WebSocket stream by issuing a CONNECT request with additional pseudo-headers like :scheme, :path, and :authority, alongside WebSocket-specific headers such as sec-websocket-protocol.

Despite the different handshake, once established, the resulting stream behaves just like a WebSocket TCP connection from the perspective of the application: bidirectional, message-based communication with binary or text frames. HTTP/2’s stream-layer features like prioritization and flow control also apply, enabling better resource sharing.

The core WebSocket protocol (RFC 6455) remains unchanged beyond the handshake; only the transport bootstrap differs.

Rama Support

📚 Rust Docs: https://ramaproxy.org/docs/rama/http/ws/index.html

With Rama’s ws or http-full feature enabled, full WebSocket support is built-in for both servers and clients. You can:

• Accept WebSocket upgrades and handle messages asynchronously
• Connect to remote WebSocket endpoints and send/receive data
• Handle disconnects (in the form of IO errors)

You are notified about meta messages such as ping/pong, close and so on. These are however also already handled for you automatically when you use the runtime API, so this is only informative. As such, you'll see that high level functionality such as a ws client/server or the built-in ws echo server only handle the text/binary messages.

There’s no hardcoded opinion about message format. Text, binary, newline-delimited, JSON, MessagePack—it’s your protocol, Rama just streams it. How you decode them is up to you. See the examples for inspiration.

Flexible transport support

From both the client and server perspective, Rama gives you full control over the transport layer used for (async) WebSocket communication.

Since WebSocket handshakes are initiated over HTTP(S), you inherit the same transport flexibility that Rama offers for all HTTP layers:

• Need secure WebSocket (WSS)? TLS is fully supported out of the box—no special handling required.
• Want to route through a proxy protocol like HAProxy, or use remote proxies such as HTTP or SOCKS5? That works the same way as any other HTTP request in Rama.
• Prefer using UNIX domain sockets instead of TCP? That’s supported too—just plug it in.

WebSocket support in rama binary

The rama CLI tool has WebSocket support:

• server-side in the echo and fingerprint commands.
  • E.g. for the echo command you can enable it using --ws
  • the public https://echo.ramaproxy.org website accepts also WebSocket connections on any endpoint
• client side with a Terminal User Interface (TUI) via the rama ws command
  • this can be a useful client to quickly test out a WebSocket service or a MITM WS Proxy;

Examples

You can find working WebSocket examples in the Rama repository: ws_echo_server.rs

• ws_echo_server.rs Simple WebSocket echo server.
• ws_echo_server_with_compression.rs Simple WebSocket echo server with compression enabled and supported (Per Message deflate).
• ws_chat_server.rs Simple WebSocket server for a basic chat room.
• ws_tls_server.rs Secure WebSocket server example (WSS).
• ws_over_h2.rs Secure WebSocket server using h2.
• autobahn_client.rs Run autobahn WebSocket test suite.

In the existing http_mitm_proxy_boring.rs example you can find inspiration on how to MITM proxy WebSocket traffic. As often it is not the only way to achieve it, but in case you didn't know yet how to begin doing so, it might be sufficient to get you started at least.

Rama’s WebSocket types integrate with its typed headers and upgrade machinery, giving you seamless access to the WebSocket handshake and stream lifecycle.
